Trios® Surgical Table System
Trios® Surgical Table System
Our latest modular table platform, offering enhanced safety features, improved setup workflows, and increased weight capacity.
Modular table system components:
- Trios Table Base Part #7803
- Trios Spinal Surgery Top Part #7943
- Trios Radiolucent Imaging Top Part #7927
- Trios Orthopedic Trauma Top Part #7855
Enhanced patient positioning for spine, imaging and orthopedic trauma
This modern system features a dual column modular platform known for its interchangeable patient positioning for spine, imaging, and orthopedic trauma procedures. Trios features a unique tabletop mounting interface that keeps the tabletop locked in place, single push electronic floor locks and a streamlined 180° patient rotation mechanism. Simple to set up and intuitive to use, Trios simplifies your workflow and minimizes the possibility of human error.
Each top works with the Trios Table Base and can be purchased individually or as part of a system.
Product features
- Tower and ratchet system that provides a unique tabletop mounting interface resulting in secure connection and adjustable table top height before and after patient transfer
- Powered floor locks
- Carbon fiber construction for complete radiolucency, allowing unrestricted C-arm and O-arm® access
- Streamlined 180° patient rotation mechanism, with two-stage locking release and clear indicator lights
- Positioning and operating functions controlled by an intelligent hand pendant, the IntelliPendant®, with two memory settings to retain the preferred position, and assist with setup
- Auxiliary panel provides a secondary source for controlling table motion
- Customizable pad and component placement to meet individual patient needs
- Tempur-Pedic® Pad technology incorporated into all patient surfaces in supine or prone positioning
Trios Spinal Surgery Top
- Open spine frame reduces vena cava compression, minimizes epidural venous bleeding and improves visualization at the surgical site
Trios Radiolucent Imaging Top
- Supports supine or lateral positions
- Fully radiolucent, carbon fiber table top with Tempur-Pedic® pressure equalization pad
Trios Orthopedic Trauma Top
- Modern table top with Traction Arc attachment features
- Traction Arc provides constant and anatomically correct traction for various trauma procedures
- Secure and flexible with multiple component options for either skin or skeletal traction
- Enhanced radiolucency by design
Positioning capabilities
Spine Surgery Top
Prone
Radiolucent Imaging Top
Supine
Lateral
Orthopedic Trauma Top
Supine
Lateral
Common procedures
* Some procedures may require additional accessories
Spinal
- Laminectomies
- Decompressions
- Osteotomies
- Anterior/posterior fusions
- Surgical correction of deformities
- Anterior/posterior cervical procedures
- Kyphoplasties
- Vertebroplasties
- IDET surgeries
Imaging
- Vascular surgery
- Joint imaging
- Pain management
Orthopedic Trauma
- Hip pinning
- Supine IM femoral nailing
- Lateral IM femoral nailing
- IM tibial nailing
- Ender pinning
Warranty
We guarantee our products for a period of one year from the date of shipment from Mizuho OSI for defects in material and workmanship with the exception of products which are misused, altered or damaged.
Patents
- US 8,341,777
- US 9,968,503
- US 11,452,657
Product specifications
| Trios Table Base | Crossbar to floor height 33–50.7” (83.8–128.8cm) Trendelenburg/Reverse Trendelenburg 10º Lateral tilt (roll) 25º Base width 32” (81cm) Base length 110” (279cm) Retracted base length 68” (173cm) |
| Trios Spinal Surgery Top | Table top length 84” (213cm) Table top width 17” (43cm) Patient weight capacity 650lbs (295kg) |
| Trios Radiolucent Imaging Top | Table top length 84” (213cm) Table top width 21.5” (55cm) Patient weight capacity 650lbs (295kg) |
| Trios Orthopedic Trauma Top | Table top length 84” (213cm) Table top width 21.5” (55cm) Patient weight capacity 500lbs (227kg) |
Standard Components
Spinal Surgery Top
- Towers (2)
- Spine Frame
- ProneView® Helmet and Mirror Platform
- Face Plate
- Tempur-Pedic® Chest Pad
- Chest Plate
- Leg Board with 1” (2.5cm) Tempur-Pedic Pad (2)
- Adjustable Leg Sling
- Buttocks Strap
- Safety Strap 60” (152cm)
- Safety Strap 90” (229cm) (4)
- Cervical Traction Vector
- Table Top Cover
Arm Boards sold separately. Quantity two (2) required.
Hip/Thigh Pad Sets sold separately. Selection of one (1) set required.
Radiolucent Imaging Top
- Towers (2)
- Tempur-Pedic Pad 2” (5cm)
- Radiolucent Imaging Platform
- Supine Top Safety Strap
- Safety Strap 60” (152cm)
- Trios 6” (15cm) Side Rail Adaptor (2)
- Table Top Cover
Orthopedic Trauma Top
- Orthopedic Table Top
- Traction Arc with Cart
- Patient Transfer Board
- Traction Unit Upright (2)
- Traction Extension (3)
- Traction Unit (2)
- Traction Boot (pairs) small and large
- Traction Foot Plate (2)
- Soft Traction Boot, (pair) small and large
- 90° Pin and Wire Holder
- Kirschner Bow Holder
- G.M.Board, right and left
- Center Support Board with Pad
- Perineal Post, child and adult
- Lateral Ilium and Perineal Post
- Tibia Counter-Traction Post and Support Upright
- Well Leg Support and Swing Arm
- Tibia Well Leg Support
- Radiolucent Auxiliary Leg Spar
- Leg Spar Upright
- Leg Board
- Lower Leg Support
- Tibia Traction Upright
- Accessory Clamp (2)
- Safety Strap (2)
- Patient Isolation Drape Hanger Posts and Rods
- Universal Side Rail Adaptor, 6” (15cm)
- Table Top Cover
Accessories (52)
Part #7803-500
Trios Equipment Cart with Cover
Part #5888
Radiolucent Retractor Adaptor for Spinal Frame
Part #5319G
Wilson Plus™ Radiolucent Frame
A radiolucent platform that supports the patient in a flexed position during lumbar procedures.
Radiolucent Adaptor for the Cervical Management Base Unit
DORO® Part #5979-300
Mayfield® Part #5979-200
DORO® is a registered trademark of pro med instruments GmbH.
Mayfield® is a registered trademark of Schaerer Mayfield USA, Inc.
Part #5873-300
DORO® Radiolucent Adaptor for the Coupler II
DORO® is a registered trademark of pro med instruments GmbH.
Part #6910-1001
DORO® QR3 Aluminum Skull Clamp
DORO® is a registered trademark of pro med instruments GmbH.
Part #6910-4004
DORO® Radiolucent Skull Clamp
DORO® is a registered trademark of pro med instruments GmbH.
Part #5879-2
Anterior Extension Positioner with Bladder
Part #5840-620
Dual Chest Pads, 1 Pair
Part #7803-457
Trios Cervical Management Base Unit
Part #7803-456
Trios Cervical Management Base Unit Mounting Bracket
Part #7803-471
Trios Coupler II Complete Assembly (includes main assembly, adapter brackets, and aluminum and radiolucent Mayfield Adaptors)
Part #7803-381
Trios Short Supine Operating Top
Part #7300
Trios Lateral Positioner Set
Part #5300-2
Shoulder and Sacral Lateral Positioner Assembly
Part #5855-865
Traction Boot with Foot Plate, X-large, Pair
Part #5932
NervPro™ System
Protects the patient’s arm peripheral nerves with natural positioning, minimizes pressure and meets ASA and AORN guidelines.
Part #6910-3006-00
DORO® Disposable Stainless Steel Skull Pins, Adult
12 pkgs. 3 pins each
DORO® is a registered trademark of pro med instruments GmbH.
Part #6910-3006-2
DORO® Disposable Titanium Skull Pins, Adult
12 pkgs. 3 pins each
DORO® is a registered trademark of pro med instruments GmbH.
Resources and Education
Trios product brochure
Memory Function, Trios
Setup instructions online or on our app
Trios training class for biomed engineers
