Symbols Glossary

Share this...
Share on facebook
Facebook
Share on twitter
Twitter
Share on linkedin
Linkedin



Symbols from Standards

SymbolStandard ReferenceStandard TitleSymbol TitleExplanatory Text
ISO 15223-1, Reference no. 5.1.2Medical devices — Symbols to be used with information to be supplied by the manufacturer — Part 1: General requirements.Authorized representative in the European CommunityThis symbol indicates the authorized representative in the European Community.
ISO 15223-1, Reference no. 5.7.7
Medical devices — Symbols to be used with information to be supplied by the manufacturer — Part 1: General requirements.Medical DeviceThis symbol indicates a medical device.

ISO 7000-3082Graphical symbols for use on equipment.ManufacturerThis symbol indicates the manufacturer of the device.
ISO 7000-2497Graphical symbols for use on equipment.Date of ManufactureThis symbol indicates the date when the device was manufactured.
ISO 7000-2493Graphical symbols for use on equipment.Catalog numberThis symbol indicates the manufacturer’s product number so that the device can be identified.
ISO 7000-2498Graphical symbols for use on equipment.Serial numberThis symbol indicates the manufacturer’s serial number so that a specific device can be identified.
ISO 7000-1135Graphical symbols for use on equipment.Batch codeThis symbol indicates the manufacturer’s batch code so that the batch or lot can be identified.
ISO 7000-2607Graphical symbols for use on equipment.Use byThis symbol indicates the date after which the device is not to be used.
ISO 7010-M002Graphical symbols —Safety colours and safety signs—Registered safety signsRefer to instruction manual/bookletThis symbol indicates that the Owner’s Manual must be read before use.
ISO 7000-1641Graphical symbols for use on equipment.Consult instructions for useIndicates that the user needs to consult instructions for use
ISO 7000-0434BGraphical symbols for use on equipment.CautionThis symbol indicates a potentially hazardous situation, which if not avoided could result in minor or moderate injury.
ISO7010-W001Graphical symbols —Safety colours and safety signs—Registered safety signsGeneral warning signThis symbol indicates a potentially hazardous situation, which if not avoided could result in serious injury or death.
ISO-7010-W012Graphical symbols —Safety colours and safety signs—Registered safety signsWarning; ElectricityThis symbol indicates Warning, dangerous voltage (related to battery safety).
ISO-7010-W012Graphical symbols —Safety colours and safety signs—Registered safety signsWarning; Flammable
material
This symbol indicates warning of flammable material.
IEC 60417-5840Graphical Symbols for use with equipmentType B applied partThis symbol indicates this equipment is an applied part TYPE B in accordance with IEC 60601-1 and is generally suitable for applications involving external or internal contact with the patient, excluding the heart. The patient circuit is connected to protective earth and this equipment should be connected only to hospital grade AC outlets with a protective earth ground
IEC 60417-5333Graphical Symbols for use with equipmentType BF applied partThis symbol indicates this equipment is an applied part TYPE BF in accordance with IEC 60601-1.
ISO 7000-1501Graphical symbols for use on equipment.Do not reuseThis symbol indicates product cannot be reused.
ISO 7000-2608Graphical symbols for use on equipment.Do not resterilizeThis symbol indicates product cannot be resterilized.
ISO 7000-2906Graphical symbols for use on equipment.Non-SterileThis symbol indicates components have not been sterilized.
IEC 60417-5638Graphical symbols for use with equipment.Emergency stopThis symbol indicates an Emergency Stop control device.
IEC 60417-5019Graphical symbols for use with equipment.Protective earth; protective groundThis symbol indicates an external ground stud that is required for use when the AC power cable is not connected to a protective earth ground hospital grade AC outlet in your operating room or facility.
IEC 60417-5021Graphical symbols for use with equipment.EquipotentialityThis symbol indicates an external ground stud that is required to be connected to earth ground (via equipotential connector / busbar) when the AC power cable is not connected to a protective earth ground hospital grade AC outlet in your operating room or facility.
IEC 60417-5032Graphical symbols for use with equipment.Alternating currentThis symbol Indicates equipment is suitable for Alternating Current (AC) power.
IEC 60417-5031Graphical Symbols for use with equipmentDirect currentThis symbol indicates equipment is suitable for Direct Current (DC) power.
IEC 60417-5001AGraphical Symbols for use with equipmentBattery, generalThis symbol indicates Battery Power.
IEC 60417-5031Graphical Symbols for use with equipmentBattery checkThis symbol indicates the Battery Status.
ISO 7000-0632Graphical Symbols for use on equipmentTemperature limitsThis symbol indicates the temperature limits to which the medical device can be exposed safely.
ISO 7000-2620Graphical Symbols for use on equipmentHumidity limitationThis symbol indicates the range of humidity to which the medical device can be exposed safely.
ISO 7000-2621Graphical Symbols for use on equipmentAtmospheric pressure limitationThis symbol indicates the range of atmospheric pressure to which the medical device can be exposed safely.
ISO 15223-1, Reference no. 5.2.8Medical devices — Symbols to be used with information to be supplied by the manufacturer — Part 1: General requirements.Do not use if package is damagedThis symbol indicates that product should not be used if packaging is damaged.
ISO 7000-0621Graphical Symbols for use on equipmentFragile, handle with careThis symbol indicates a medical device that can be broken or damaged if not handled carefully.
ISO 7000-0626Graphical symbols for use on equipment.Keep away from rainThis symbol indicates a medical device that needs to be protected from moisture.
ISO 7000-0623Graphical symbols for use on equipment.This way upThis symbol indicates “This End Up,” and identifies the correct orientation for safe handling.
ISO 7000-2402Graphical symbols for use on equipment.Do not stackThis symbol indicates items are not to be vertically stacked.
ISO 7000-2794Graphical symbols for use on equipment.Packaging unitThis symbol indicates the number of pieces in the package.
IEC 60417-5390Graphical symbols for use with equipment.Patient, normalThis symbol indicates a reference to a normal patient.
ISO 7000-2501Graphical symbols for use on equipment.Sterilized using ethylene oxideThis symbol indicates product was sterilized using ethylene oxide.
ISO 7000-2502Graphical symbols for use on equipment.Sterilized using irradiationThis symbol indicates product was sterilized using irradiation.
ISO 7000-3650Graphical symbols for use on equipment.Universal Serial Bus (USB), port/plugThis symbol identifies a USB port.
ISO 7000-1135Graphical symbols for use on equipment.General symbol for
recovery/recyclable
This symbol indicates that the marked item or its material is part of a recovery or recycling process.
IEC 60417-5008Graphical symbols for use with equipment.“OFF” (power)This symbol identifies Power Off.
IEC 60417-5007Graphical symbols for use with equipment.“ON” (power)This symbol identifies Power On.
IEC 60417-5009Graphical symbols for use with equipment.Stand-byThis symbol identifies a Power/Standby switch.
IEC 60417-5569Graphical Symbols for use with equipment.Locking, generalThis symbol indicates the locked state.
IEC 60417-5570Graphical Symbols for use with equipment.Unlocking, generalThis symbol indicates the unlocked state.
IEC 60417-5988Graphical Symbols for use with equipment.Computer networkThis symbol identifies connecting terminals to a computer network like an ethernet cable inlet.
IEC 60417-6378Graphical Symbols for use with equipment.Foot controlThis symbol identifies a foot control device, connection or function.
IEC 60417-5114Graphical Symbols for use with equipment.Foot switchThis symbol identifies a foot switch or the connection for a foot switch.

Symbols not from Standards

SymbolStandard ReferenceStandard TitleSymbol TitleExplanatory Text
Regulation (GB) SI
2019/696
The Product Safety and Metrology etc. (Amendment etc.) (EU Exit) Regulations 2019: Schedule 33UKCA markingThis symbol indicates that a product is in conformity with the relevant United Kingdom legislation.
Regulation (EC) No 765/2008The requirements for accreditation and market surveillance relating to the marketing of productsCE markingThis symbol indicates that a product is in conformity with European Community harmonisation legislation.
N/AN/AContents; quantityThis symbol indicates contents or quantity.
N/ADirective 2012/19/EUWEEE symbolThis symbol indicates proper disposal instructions.
N/AN/AProblem indicatorThis symbol may indicate a problem or contact information in case of a problem.
N/AN/APinch PointThis symbol indicates a pinch hazard
N/AN/ADo not touch - ElectricityThis symbol indicates Do not touch, housing energized (related to battery safety).
N/AN/AConnectedThis symbol indicates components are properly connected and receiving power.
N/AN/ACircuit breakerThis symbol indicates a Circuit Breaker.
N/AN/AWeight limitThis symbol indicates the weight limit the table can support.
N/AN/ABattery chargeThis symbol indicates Battery charge status.
N/AN/ABattery OKThis symbol identifies the Battery OK LED or Battery Status LED.
N/AN/AStandard Performance (EN 13795)This symbol indicates product meets Standard Performance (SP) of EN 13795.
N/AN/AHigh Performance (EN 13795) This symbol indicates product meets High Performance (HP) of EN 13795.
N/AN/ALevel 3 DrapeThis symbol indicates that the drape meets AAMI Level 3 requirements
for liquid barrier performance.
N/AN/ALevel 4 DrapeThis symbol indicates that the drape meets AAMI Level 4 requirements for liquid barrier performance.
N/AN/ACut hereThis symbol indicates where something can be cut.
N/AN/ANo latexThis symbol indicates product was not made with natural rubber latex.
N/AN/ANo phthalatesThis symbol indicates product was not made with phthalate materials.
